Flat steel is steel with a width of 12-300 mm and a thickness of 3-60 mm, rectangular in cross-section and with slightly blunt edges. Flat steel can be finished steel, but can also be used as billets for welded pipes and as slabs for stacked rolled sheets. The main uses: flat steel as a finished material can be used for hoop iron, tools and mechanical parts, and in construction as structural parts of the house frame, escalators.

product details.png

Specification	25-400mm*200-800mm
Length	3000mm-12000mm, or as per requirements
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS etc.
Technology	Bright, Polished, Turn smooth(Peeled),Brush, Mill, Pickled etc.
Quality	We can offer the certifications of chemical compostion and mechanical property
Grades	201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.410.440.904Lect. Or Customized
Package	Export standard package, bundled or be required.
Delivery	7-15 days after deposit
Sample	We could offer the sample for free charge but do not pay the cost of freight

Product Display.png

Size and Weight:

Width	Thickness(mm)
	3	4	5	6	8	10	12	14	16	20	25	30
mm	Theoretic Weight kg/m
10	0.238	0.32	0.4	0.48	0.63
15	0.36	0.48	0.59	0.71	0.95	1.19
20	0.476	0.63	0.79	0.95	1.27	1.59	1.9
25	0.585	0.79	0.99	1.19	1.59	1.98	2.38
30	0.714	0.95	1.19	1.43	1.9	2.38	2.85	3.33	3.81	4.758	5.948
40	0.952	1.27	1.59	1.9	2.54	3.17	3.81	4.44	5.08	6.34	7.93	9.52
50	1.19	1.59	1.98	2.38	3.17	3.97	4.76	5.55	6.34	7.93	9.91	11.9
60	1.428	1.9	2.38	2.85	3.81	4.76	5.71	6.66	7.61	9.52	11.9	14.27
70		2.22	2.78	3.33	4.44	5.55	6.66	7.77	8.88	11.1	13.88	16.65
80			3.17	3.81	5.08	6.34	7.61	8.88	10.15	12.69	15.86	19.03
90			3.57	4.28	5.71	7.14	8.56	9.99	11.42	14.27	17.84	21.41
100			3.97	4.76	6.34	7.93	9.52	11.1	12.69	15.86	19.82	23.79
110				5.23	6.98	8.72	10.47	12.21	13.96	17.45	21.81	26.17
120				5.71	7.61	9.52	11.42	13.32	15.23	19.03	23.79	28.56
130				6.19	8.25	10.31	12.37	14.43	16.49	20.62	25.77	30.93
140				6.66	8.88	11.1	13.32	15.54	17.76	22.2	27.76	33.31
150				7.14	9.52	11.9	14.27	16.65	19.03	23.79	29.74	35.69
160				7.61		12.6	15.23	17.76	20.3	25.38	31.72	38.06
170						13.48	16.18	18.87	21.57	26.96	33.7	40.44
180						14.27	17.13	19.98	22.84	28.55	35.69	42.82

Product Surface.png

SURFACE	CHARACTERISTIC	SUMMARY OFMANUFACTURING METHOD	APPLICATION
NO.1	Silvery white	Hot rolled to specified thickness	Do not need to have a glossy surface use
	Lackluster
NO.2D	Silvery white	After cold rolling, heat treatment and pickling are carried out	General material,deep material
NO.2B	Gloss is stronger than NO.2D	After NO.2D treatment,the final light cold rolling is carried out through the polishing roller	The general material
BA	As bright as a sixpence	No standard,but usually a bright annealed surface with high reflectivity	Building materials,kitchen utensils
NO.3	Rough lapping	Grind with 100-200#(unit)strop tape	Building materials,kitchen utensils
NO.4	Intermediate grinding	Polished surface obtained bygrinding with150~ 180# strop abrasive tape	Building materials,kitchen utensils
NO.240	Fine lapping	Grinding with 240# strop abrasive tape	Kitchenware
NO.400	The luster is close to BA	Use 400# polishing wheel to grind	General,timber,building,timber,kitchen appliances
HL	Hairline grinding	Suitable particle material for hair stripe grinding(150~240#)with many grains	Building.construction material
NO.7	It s close to mirror grinding	Use a 600# rotary polishing wheel to grind	For art or decoration
NO.8	Mirror ultra finish	The mirror is ground with a polishing wheel	Reflector,for decoration
