Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer, thereby combining the substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel parts first. In order to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned in an ammonium chloride or zinc chloride aqueous solution or a mixed solution of ammonium chloride and zinc chloride.And then sent to the hot-dip plating bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life.

product details.png

1	Commodity	Hot-dipped Galvanized Steel Coils
2	Technical Standard	ASTM A653
3	Grade	GR50 / GR340
4	Thickness	0.14- 8.0mm
5	Width	600mm - 1500mm
6	Zinc coating	Z30 – Z275
7	Surface treatment	Chromed(Cr3+/CR6+) / Anti-finger print(AFP) / Chrome Free/ Oiled / Slightly oiled / Dry
8	Spangle	Zero spangle/small spangle/regular spangle
9	Coil ID	508mm or 610mm
10	Coil weight	4mt ~8mt or as customer's requirement
11	MOQ per size	25MT
12	Package	Sea worth export standard package
13	Application	Industrial panels, roofing and siding for painting
14	Price term	FOB, CFR, CIF
15	Payment term	T/T., LC At Sight
16	Delivery time	Upon the final quantity you demand and normally 30-45 days

A table of Grades according to JIS 3302 Standard:

Type of Base steel	Grade	Thickness mm	Application
Hot rolled steel	SGHC	≥1.6~6.0	Common
	SGH340		Structural
	SGH400
	SGH440
	SGH490
	SGH540
Cold rolled steel	SGCC	≥0.25~3.2	Common
	SGCH	≥0.11~1.0	Common hardness
	SGCD1	≥0.40~2.3	deep draw class 1
	SGCD2	≥0.40~2.3	deep draw class 2
	SGCD3	≥0.60~2.3	deep draw class 3
	SGC340	≥0.25~3.2	Structural
	SGC400
	SGC440
	SGC490
	SGC570	≥0.25~2.0
